Effect of Moisture & Temperature on the bonding of Adhesives & Sealants
Key Takeaways
- The impact of moisture and temperature on adhesive and sealant bonding.
- Types of curing systems: Moisture cure, moisture loss, and solvent loss.
- The difference between wet vs. damp and their effects on bonding.
- How ambient and substrate temperatures affect curing rates.
- Best practices for using adhesives in varying moisture and temperature conditions.
Moisture and temperature play a critical role in the effectiveness of adhesives and sealants, influencing the bonding process in various ways. Understanding the different curing systems, including moisture cure, moisture loss, and solvent loss, is essential for achieving the best results. This article explores the effects of moisture and temperature on curing rates, the differences between wet and damp conditions, and provides practical advice for ensuring strong adhesive bonds in different environmental settings.
3 Main Types of Curing Systems
Curing System |
Types of Products |
Moisture Cure (or Condensation Cure) | MS Polymers Polyurethanes Silicones |
Moisture Loss | PVA’s Acrylic Wallboard Adhesives Acrylic Gap Fillers |
Solvent Loss | Synthetic Rubber/Resins |
Clause E2 External Moisture E2/AS1 at time of completion
NZBC |
% |
Lining System Suppliers |
% |
For timber framing at the time of installing interior linings | 20% | GIB Aqualine Wet Area Systems | 18% |
For timber weatherboards and exterior joinery at the time of installation | 18% or less | Kopine Ultralock | 18% |
For reconstituted wood products | 18% | Seratone | 18% |
H1.1 and H1.2 treated framing | 20% max | HardiGlaze | 18% |
Kiln-dried untreated timber | 18% max | Hydrapanel | 18% |
Window Sill Tapes (Traditional) | 12-14% |
Moisture & its Impact on Curing Systems
What is “ Wet vs. Damp” when it comes to curing systems?
Wet |
Damp |
Means you can even strain water from the item/object. ie: if you can ring water from a hat it is wet |
Means that you can smell the presence of water in the object. ie: if the hat feels “clammy” it is likely to be damp. |
Cure System – Moisture Cured
What does Cure System – Moisture Cured mean?
Too much moisture |
Too little moisture |
The GRAB not being made to the substrate | The bond does not set, as not enough of a curing reaction has taken place |
Cure System – Moisture Loss
What does Cure System – Moisture Loss mean?
Too much moisture |
Too little moisture |
Possible diluted strength at the adhesive bond line between the substrate and the adhesive/sealant. |
Generally not a bad thing as moisture is absorbed into the substrate/air. |
Cure System – Solvent Loss
What does Cure System – Solvent Loss mean?
Too much moisture |
Too little moisture |
The GRAB not being made to the substrate
The adhesive may skin before adhesion takes place |
Not such a bad thing
More solvent is absorbed back into the timber initially |
Temperature & its impact on Curing Systems
- In discussing curing rates and ambient temperature the process is logarithmic NOT linier
- Therefore: The rate at which curing takes place could very well be MUCH longer than your would normally expect
Substrate Temperature
- Not only is the ambient air temperature important, BUT
- You also need to manage both the substrate (substrate surface & substrate internal) temperature.
- Many adhesives and sealants require a minimum substrate surface temperature of not less than 5˚C (also depending on local conditions, you can get “micro-frosts” which will prevent bonding at lower temperatures).
Moisture Cured
What does moisture cured mean?
At low temperatures
- The adhesive takes much longer to set, or does not set at all. Where items have been clamped they may come apart once the clamps have been removed
- More chance of dirt sticking to sealant joints as it doesn’t skin off
- The bond does not set, as not enough of a curing reaction has taken place
Moisture Loss
What does moisture loss mean?
At low temperatures
- The adhesive takes much longer to set, or does not set at all, until temperatures increase
Solvent Loss
What does solvent loss mean?
At low temperatures
- The GRAB not being made to the substrate
- The adhesive may skin before adhesion takes place
- If ambient temperature increases but the substrate temperature does not then there is a possibility of the adhesive skinning before a full bond is created
How are MS “Hybrid” Polymer’s
Effected by changing temperatures
- Published curing/skinning times change with variances in temperature & moisture.
- Curing is logarithmic over time.
- While curing/skinning times are given based on 20°C, 65%R.H., the reality is that in a 24 hour period temperatures constantly change, which can result in apparent longer cure times.
- As temperatures approach 10°C and go below this, the curing process goes into a state of stasis (hibernation). As temperatures increase, so the curing process continues.
W&G Assoc NZ – Window Systems
Moisture & temperature
- Temperature & moisture can effect the bonding of many window/sill tapes.
- When sealing against timber, you should always consider the moisture content of the timber and the temperature at the surface of the substrate
- Sealing against the building wrap and or the window sill tapes can be impaired
- Plastizor Migration changes, especially in warm conditions
- Good practice (in residential fitting) is to seal directly between the “scriber” and the exterior cladding where possibly with a MS based polymer, to create a seal.
- In cold conditions do not trim back PU based expanding foam before it is fully cured
- When sealing against timber, you should always consider the moisture content of the timber and the temperature at the surface of the substrate
In Conclusion
- Both moisture in the substrate and temperature have a big impact on the success of bonding systems
- Curing rates are logarithmic when taking into account against moisture and temperature
- The success of the use of adhesive and sealants to get the best out of them requires awareness and planning
- An increase in the use of adhesive and sealant bonding systems are coming to a construction site near you
